| Model | KME08 |
| Engine Model | KOOP192F |
| Power Type | Single-cylinder/Four-stroke/Air-cooled/Vertical |
| Fuel Type | Diesel |
| Displacement (cc) | 499 |
| Rated Power (kW/rpm) | 7.6/3000 |
| Horsepower (HP) | 10.3 |
| Fuel Tank Capacity (L) | 5.5 |
| Overall Dimensions (mm) | 2040/3570*720*2170 |
| Machine Weight (kg) | 630 |
| Bucket Capacity (m³) | 0.02 |
| Track Ground Contact Length (mm) | 860 |
| Track Width (mm) | 150 |
| Max. Digging Depth (mm) | 1300 |
| Max. Dumping Height (mm) | 1500 |
| Max. Digging Height (mm) | 2150 |
| Max. Digging Radius (mm) | 2600 |
| Gradeability (°) | 30 |
| Travel Speed (km/h) | 0-3 |
| Bucket Digging Force (kN) | 6.5 |
