| Engine | 7HP, Single cylinder, four stroke, air cooling |
| Power | 4.8kw |
| Displacement | 212cc |
| Max. Chipping Diameter | 70mm |
| N.W./G.W. | 78kg/93kg |
| Type of Fuel | Gasoline |
| Fuel tank capacity | 3.6L |
| Oil capacity | 0.55L |
| Starting method | Manual |
| Recommended Oil | 10W-30 oil (5W-30 is recommended for cold weather climate) |
| Wheel Tire | 4.10/3.5-4 |
| Cutting method | Drum |
| Blade Nos. | 2×cutting knives, 1 fixed knife |
| Drive | Direct connection |
| Chip speed | 3600rpm/min |
| Discharge chute size | 100x75 |
| Feeding chute size | 110x100 |
| Wood chips size | 8-20mm |
| External dimensions | 1840x550x1160mm |
| Package Size | 880*565*660mm |
| 40HQ Loading Qty. | 208units |
