| Model: | TWS25 | TWS30 | TWS35 |
| Split Force: | 25t（Depending on the tractor） | 30t（Depending on the tractor） | 35t（Depending on the tractor） |
| Log Capacity: | 630mm | 630mm | 630mm |
| Recommended hydraulic system pressure for tractors | 15-28MPa | 15-28MPa | 15-28MPa |
| Cylinder inner Diameter: | 4inch | 4.5inch | 5inch |
| Hydraulic Rod Diameter: | 44.5mm | 44.5mm | 44.5mm |
| Hydraulic Cylinder Stroke: | 600mm | 600mm | 600mm |
| Size of cleaver: | 200mm | 200mm | 200mm |
| Tractor mounted | CAT1, CAT2 | CAT1, CAT2 | CAT1, CAT2 |
| Recommended hydraulic flow rate for tractors | 8-12GPM | 10-15GPM | 13-18GPM |
| Overall dimensions: | 1795*796*1006mm | 1795*796*1006mm | 1795*796*1006mm |
